Processor
The HP Z2 G5 Mini has one LGA1200 processor socket supporting one Intel Xeon W-series or Intel Core i7/i9 processor. Multiple processor cores allow you to run multiple applications simultaneously and boost clock speeds up to 4.8 GHz increasing performance in both single-threaded and multithreaded applications.
Intel Core 10th Gen.
Intel Core i5-10500 (6 cores, 3.1GHz base, 4.5GHz turbo) $
Intel Core i7-10700 (8 cores, 2.9GHz base, 4.8GHz turbo) $
Intel Xeon
Intel Xeon W-1250 (6 cores, 3.3GHz base, 4.7GHz turbo) $
Memory
The HP Z2 Mini G5 has 2 SO-DIMM Slots supporting up to 64GB DDR4 Memory. Core i7/i9 processors support UDIMM (unbuffered) memory. Xeon processors support ECC (error correcting) memory. Choose more memory to improve overall system performance.
16GB of 3200MHz DDR4 Memory $
16GB of 3200MHz DDR4 ECC Memory $
32GB (2x 16GB) of 3200MHz DDR4 Memory $
32GB (2x 16GB) of 3200MHz DDR4 ECC Memory $
64GB (2x 32GB) of 3200MHz DDR4 Memory $
64GB (2x 32GB) of 3200MHz DDR4 ECC Memory $
Storage | M.2 more info
The HP Z2 G5 Tower has 2 slots for M.2 NVMe SSDs. We recommend a NVMe SSD as the primary boot drive for the operating system and applications. A 2nd NVMe SSD can be added as a dedicated work drive for active projects files - CAD files, footage, photos, etc. NVMe M.2 SSDs perform at 2,500MB/s read and 2,000MB/s write.
M.2 Slot 1
M.2 Slot 2
256GB NVMe M.2 Solid-State Drive $
512GB NVMe M.2 Solid-State Drive $
1TB NVMe M.2 Solid-State Drive $
2TB NVMe M.2 Solid-State Drive $
4TB NVMe M.2 Solid-State Drive $
8TB NVMe M.2 Solid-State Drive $
None $
256GB NVMe M.2 Solid-State Drive $
512GB NVMe M.2 Solid-State Drive $
1TB NVMe M.2 Solid-State Drive $
2TB NVMe M.2 Solid-State Drive $
4TB NVMe M.2 Solid-State Drive $
8TB NVMe M.2 Solid-State Drive $
Storage | SATA
The HP Z2 G5 Mini has 1 slot for a 2.5-inch SATA SSD. You can select a SATA SSD for storage, backup, or project files. SATA SSDs perform at 550MB/s read and 500MB/s write.
None $
250GB SATA 2.5" Solid-State Drive $
500GB SATA 2.5" Solid-State Drive $
1TB SATA 2.5" Solid-State Drive $
2TB SATA 2.5" Solid-State Drive $
4TB SATA 2.5" Solid-State Drive $
8TB SATA 2.5" Solid-State Drive $
Graphics
The HP Z2 G5 Mini supports one graphics card and has 3x DisplayPort 1.4 outputs.
Integrated Intel UHD Graphics 630 $ more info
NVIDIA Quadro P620 2GB $ more info
NVIDIA Quadro T1000 4GB Graphics $ more info
NVIDIA Quadro T2000 4GB Graphics $ more info
Wireless + Bluetooth
The Z2 G5 Mini comes standard with 1x RJ-45 1Gb Ethernet port and Wi-Fi 6E and BT 5.0.
Wi-Fi 6E (802.11ax); Dual-Band (2.4 & 5 GHz) & BT 5.0 $
Operating System
Choose the operating system that best fits your application requirements.
None $
Windows
Windows 10 Professional 64-bit $
Linux Distributions
Ubuntu 20.04.1 LTS 64-bit $
CentOS Stream 8 64-bit $ more info
Keyboard
Choose your keyboard.
None $
HP USB Keyboard $
HP Wireless Keyboard $
Mouse
Choose your mouse.
None $
HP USB Optical Mouse $
HP Wireless Optical Mouse $
3Dconnexion
None $
3Dconnexion USB CADMouse $ more info
3Dconnexion USB SpaceMouse Compact $ more info
3Dconnexion USB SpaceMouse Pro $ more info
3Dconnexion USB SpaceMouse Enterprise $ more info
3Dconnexion Wireless CADMouse Pro $ more info
3Dconnexion Wireless SpaceMouse $ more info
3Dconnexion Wireless SpaceMouse Pro $ more info
Condition more info
New $
Talk to a Specialist
(310) 844-6661
sales@x.solutions
Ships from Los Angeles, CA
Specifications
Save Configuration
Want to save this unique configuration or share it with someone? Simply click the save button and we'll provide you with a link.
Create Quote
Add your configuration(s) to your cart if you would like to create a personalized quote.
Configuration Help
Have more questions about your configuration? Need professional assistance? We are here to help!
Click the Contact Us button to fill out a contact form with your current configuration or call us at (310) 844-6661.
$50.00 shipping per unit · Free local pickup
2 Year Warranty · Condition: New
Allow 2 to 3 weeks for preparation.
See Policies for details.
$ 1,500
Get even more high-end performance packed into an insanely small device. Take on 3D design projects and work in multiple pro apps easily. Widely versatile, it's the obvious choice for the modern workplace.
Be uncompromising about performance
With new Intel® processor options and professional graphics options, you get reliable performance in multi-threaded apps. Don't worry about overheating—our advanced thermals keep things cool and quiet.
The perfect fit, anywhere
Create the ideal setup—from the office to the shop floor to the data center. Mount under a desk or behind a display then connect to multiple screens and other hardware. Or centrally manage your fleet of mini's with versatile rack mounting options.
We test it so you can trust it. 24/7.
We know you need performance you can rely on. That's why our products endure over 360K hours of rigorous testing, MIL-STD testing and software certifications.
HP's most secure workstation.
Advanced security features come standard on every Z2 Mini. System safeguards like the industry’s first self-healing BIOS help lock your device, data and identity down tight.

Manufacture Year(s)	2020 - current
Form Factor	Mini Portable PC Rackable - 7 per 5U
Processor Socket	LGA 1200
Processor Family	Intel Xeon W-1000 Processor Family Intel Core i7/i9 Processor Family
Processors	Intel Xeon W-1200 series processors Intel Core 10th Gen processors
Memory	2 SODIMM Slots 3200MHz DDR4 ECC RDIMMs (up to 64 GB) - Supported with Xeon W Series CPUs DDR4 Non-ECC UDIMMs (up to 64GB) supported with Core i7/i9 Series CPUs
Internal Storage	1x 2.5" (SATA) 2x M.2 2280 PCIe x4 (NVMe)
Audio	Realtek HD ALC221
Communications	Ethernet: 1 x RJ45 (Gigabit) Wi-Fi: Wi-Fi 6E (802.11ax); Dual-Band (2.4 & 5 GHz) Bluetooth: 5.0
Ports and Connectors	4 x USB Type-A (USB 3.1 / USB 3.2 Gen 2) 2 x USB 3.1 / USB 3.2 Gen 2 3 x DisplayPort 1.4 Output 1 x 1/8" / 3.5 mm Headphone/Microphone/Line Input/Output
Power	280 W power supply
Dimensions (W x D x H)	8.5 x 8.5 x 2.28" / 215.9 x 215.9 x 57.91 mm
Weight	4.6 lb / 2.1 kg
